Road Bike
Model :
CB-RA001
MODEL CB-RA001 ROAD BIKE W/ULTEGRA
FRAME CB-RA001 700C ALLOY ROAD
FORK 700C ROAD CARBON UD
| HEADSET | FSA NO.42-ACB | |||
| CRANKSET | SHIMANO ULTEGRA 50x34T | |||
| BRAKES | SHIMANO ULTEGRA | |||
| WHEELS | KINLIN XR-200 | |||
| TIRE | VITTORIA OPEN CORSA EVO CX 700Cx23 | |||
| DERAILLEUR | SHIMANO ULTEGRA | |||
| SPROCKET | SHIMANO ULTEGRA 11-28T | |||
| FRAME SIZES | 42cm | 45cm | 48cm | 51cm | 54cm | 57cm | |
| A | SEAT TUBE(ST) | 420 | 450 | 480 | 510 | 540 | 570 |
| B | TOP TUBE(TT) | 518 | 525 | 540 | 545 | 562 | 581 |
| C | HEAD TUBE LENGTH(HT) | 90 | 105 | 110 | 120 | 135 | 150 |
| D | HEAD TUBE ANGLE(HTA) | 72 | 72 | 72.5 | 72.5 | 73 | 73 |
| E | SEAT TUBE ANGLE(STA) | 75 | 75 | 74 | 74 | 73.5 | 73 |
| F | CHAIN STAYS(CS) | 405 | 405 | 405 | 405 | 408 | 408 |
| G | WHEEL BASE(WB) | 967.39 | 975.2 | 976.55 | 982.74 | 993.52 | 1007.47 |
| H | STACK(S) | 491.81 | 506.08 | 512.46 | 520 | 535.96 | 550.31 |
| I | REACH(R) | 386.22 | 390.67 | 393.05 | 395.89 | 404.66 | 412.75 |
| J | STAND OVER HEIGHT(SH) | 703.7 | 722 | 736 | 755.5 | 776 | 794.8 |
| K | BOTTOM BRACKET DROP(BD) | 70 | 70 | 70 | 68 | 68 | 68 |
| L | FORK LENGTH(FO) | 370 | 370 | 370 | 370 | 370 | 370 |
