Hardtail Bike
Model :
CB-MA003
MODEL CB-MA003 29" MTB W/DEORE
FRAME CB-MA003 29" ALLOY MTB FRAME
FORK ROCK SHOX 30 GOLD TK 29" TAPERED
| HEADSET | FSA NO.42-ACB | |||
| CRANKSET | FSA CK-7154NST 38x24T | |||
| BRAKES | SHIMANO BR-M395 | |||
| WHEELS | MAVIC XM-319 | |||
| TIRE | CONTINENTAL X-KING 29"x2.2" | |||
| DERAILLEUR | SHIMANO DEORE | |||
| SPROCKET | SHIMANO CS-HG50-10 11-36T | |||
| FRAME SIZES | 15" | 17" | 19" | 21" | |
| A | SEAT TUBE(ST) | 380 | 430 | 480 | 530 |
| B | TOP TUBE(TT) | 560 | 580 | 600 | 620 |
| C | HEAD TUBE LENGTH(HT) | 105 | 110 | 125 | 136 |
| D | SEAT TUBE ANGLE(STA) | 72 | 72 | 72 | 72 |
| E | HEAD TUBE ANGLE(HTA) | 71 | 71 | 71 | 71 |
| F | CHAIN STAYS(CS) | 430 | 430 | 430 | 430 |
| G | WHEEL BASE(WB) | 1030.8 | 1050.9 | 1071 | 1091 |
| H | REACH(R) | 363 | 383 | 401.6 | 421.6 |
| I | STACK(S) | 607 | 607 | 612 | 612 |
| J | STAND OVER HEIGHT(SH) | 771.9 | 795.9 | 824 | 851.8 |
| K | BOTTOM BRACKET DROP(BD) | 45 | 45 | 45 | 45 |
| FORK LENGTH(FO) | 490 | 490 | 490 | 490 |
